artglob.h File Reference
classes for initializing the artbase modules, and set paths to be used for fonts etc. More...
#include "wx/wx.h"
#include <wx/module.h>
#include "wx/geometry.h"
#include "wx/general/genmod.h"
#include <wx/dynarray.h>
#include <wx/listimpl.cpp>
Include dependency graph for artglob.h:
This graph shows which files directly or indirectly include this file:
Go to the source code of this file.
Classes | |
| class | a2dArtBaseModule |
| initiation module for the wxArt2D library More... | |
| class | a2dGlobal |
| class for storing paths and settings, which are used within the artbase module. More... | |
| class | a2dDoMu |
| store and convert number to number with unit and visa versa. e.g. 1.23e-6 => 1.23 * 1e-6 More... | |
| class | a2dAET |
| Used internal for scanned ( gradient etc. ) polygon filling. More... | |
Defines | |
| #define | A2DARTBASEDLLEXP |
| #define | A2DARTBASEDLLEXP_DATA(type) type |
| #define | A2DARTBASEDLLEXP_CTORFN |
| #define | a2dACCUR 1e-6 |
| accuracy used to have some limit to calculation like hittesting | |
| #define | Round(x) (int) floor( (x) + 0.5 ) |
| round to integer such that e.g 2.5 < x < 3.5 becomes 3 | |
Typedefs | |
| typedef wxPoint2DDouble | a2dPoint2D |
| this to define if coordinate numbers are integer or doubles | |
Enumerations | |
| enum | a2dDrawStyle { a2dFILLED, a2dWIREFRAME, a2dWIREFRAME_ZERO_WIDTH, a2dWIREFRAME_INVERT, a2dWIREFRAME_INVERT_ZERO_WIDTH, a2dFIX_STYLE, a2dFIX_STYLE_INVERT } |
| Define the manner in which a2dCanvasView draws to the device. More... | |
Functions | |
| double | wxDegToRad (double deg) |
| conversion from degrees to radians | |
| double | wxRadToDeg (double rad) |
| conversion from radians to degrees | |
| void | Aberration (double aber, double angle, double radius, double &dphi, unsigned int &segments) |
| calculate number of segments in an arc such that a certain accuracy is maintained | |
| double | wxSqr (double x) |
| good replacement for pow(x,2) | |
| WX_DECLARE_LIST_WITH_DECL (a2dAET, a2dAETList, class) | |
| Holds Active edge table. Used internal for scanned ( gradient etc. ) polygon filling. | |
| WX_DECLARE_LIST_WITH_DECL (int, a2dCriticalPointList, class) | |
| Holds local minimums in polygon. Used internal for scanned ( gradient etc. ) polygon filling. | |
| WX_DECLARE_LIST_WITH_DECL (wxRegion, a2dClipRegionList, class) | |
| Holds all clipping regions within a a2dCanvasView. | |
Variables | |
| const double | wxPI |
| defines PI | |
| a2dGlobal * | a2dGlobals |
| global a2dCanvasGlobal to have easy access to global settings | |
| const int | SPLINE_STEP = 20 |
| number of steps when converting a spline to lines. | |
Detailed Description
classes for initializing the artbase modules, and set paths to be used for fonts etc.Copyright: 2000-2004 (c) Klaas Holwerda
Licence: wxWidgets Licence
RCS-ID:
- Id
- artglob.h,v 1.23 2009/08/20 20:39:37 titato Exp
Definition in file artglob.h.
