a2dDragMultiTool Class Reference
[Objects used for interactive manipulation.]
Drag Selected canvasObjects.
More...
#include <sttool.h>
Public Member Functions | |
| a2dDragMultiTool (a2dStToolContr *controller) | |
| bool | ZoomSave () |
| Is Zooming while the tool is busy Save. | |
Static Public Attributes | |
| static const a2dCommandId | COMID_PushTool_DragMulti |
| push this tool on the tools stack | |
Protected Member Functions | |
| void | OnChar (wxKeyEvent &event) |
| called on key events | |
| void | OnMouseEvent (wxMouseEvent &event) |
| called on mouse events | |
| virtual bool | EnterBusyMode () |
| starts a new action (e.g drawing something ) in a tool that is already pushed. | |
| virtual void | FinishBusyMode (bool closeCommandGroup=true) |
| Called when the user finishes editing a distinct object */. | |
| virtual void | AbortBusyMode () |
| Called when the user aborts editing a distinct object */. | |
| void | CaptureMouse () |
| redirect all mouse events for the canvas to this object | |
| void | ReleaseMouse () |
| release the mouse capture for this object | |
| void | DragAbsolute (double x, double y) |
| virtual void | Render () |
| render in drag style | |
| virtual void | AdjustShift (double *x, double *y) |
| This is overriden by copy tools to have a minimum distance between original and copy. | |
| virtual wxString | GetCommandGroupName () |
| return the command group name for commands of a derived class | |
| virtual bool | CreateToolObjects () |
| Create the editcopy and other tool objects (e.g. decorations). | |
| virtual void | CleanupToolObjects () |
| Cleanup the editcopy other tool objects (e.g. decorations). | |
Protected Attributes | |
| a2dCanvasObjectList | m_objects |
| the list of selected objects | |
| a2dCanvasObjectList | m_connectedwirecopies |
| the list of connectedwire editcopies | |
| double | m_startObjectx |
| hold start of drag | |
| double | m_startObjecty |
| hold start of drag | |
| double | m_startMousexw |
| hold start of drag | |
| double | m_startMouseyw |
| hold start of drag | |
Detailed Description
Drag Selected canvasObjects.
- See also:
- a2dStToolContr
Definition at line 1833 of file sttool.h.
Member Function Documentation
| bool a2dDragMultiTool::ZoomSave | ( | ) | [inline, virtual] |
Is Zooming while the tool is busy Save.
If so, the active tool will redraw itself in the new Mapping state
Implements a2dBaseTool.
| bool a2dDragMultiTool::EnterBusyMode | ( | ) | [protected, virtual] |
starts a new action (e.g drawing something ) in a tool that is already pushed.
Opens a new a2dCommandGroup, which will be closed at the end of an action. This is normally in FinishBusyMode(), but might be delayed when other tools are pushed, like the edit tool to further edit the drawn figure. This should become part of the same command group.
Reimplemented from a2dStTool.
Definition at line 6120 of file sttool.cpp.
| void a2dDragMultiTool::FinishBusyMode | ( | bool | closeCommandGroup = true |
) | [protected, virtual] |
Called when the user finishes editing a distinct object */.
- See also:
- EnterBusyMode,
GetActive You should call the base class (this) version at the END of your function
Reimplemented from a2dStTool.
Definition at line 6128 of file sttool.cpp.
| void a2dDragMultiTool::AbortBusyMode | ( | ) | [protected, virtual] |
Called when the user aborts editing a distinct object */.
- See also:
- EnterBusyMode This is supposed to undo aeverything the tool did since entering busy mode
Reimplemented from a2dStTool.
Definition at line 6148 of file sttool.cpp.
| virtual wxString a2dDragMultiTool::GetCommandGroupName | ( | ) | [inline, protected, virtual] |
return the command group name for commands of a derived class
this defaults to the class name
Reimplemented from a2dBaseTool.
Reimplemented in a2dCopyMultiTool.
| bool a2dDragMultiTool::CreateToolObjects | ( | ) | [protected, virtual] |
Create the editcopy and other tool objects (e.g. decorations).
m_original must be set before this function is called
Reimplemented from a2dStTool.
Definition at line 6237 of file sttool.cpp.
The documentation for this class was generated from the following files:
