a2dDragNewTool Class Reference
[Objects used for interactive manipulation.]
Interactive drag a new object into a drawing.
More...
#include <sttool.h>
Public Member Functions | |
| a2dDragNewTool (a2dStToolContr *controller, a2dCanvasObject *newObject) | |
| bool | ZoomSave () |
| Is Zooming while the tool is busy Save. | |
| void | OnMouseEvent (wxMouseEvent &event) |
| called on mouse events | |
| virtual void | AdjustRenderOptions () |
| Adjust the rendering options to the needs of this tool. | |
Static Public Attributes | |
| static const a2dCommandId | COMID_PushTool_DragNew |
| push this tool on the tools stack | |
Protected Member Functions | |
| void | OnComEvent (a2dComEvent &event) |
| called when a tool has changed (fill stroke layer spline ) | |
| void | OnEnter (wxMouseEvent &event) |
| when dragging an object from another window into the tool its window, this window wants to have the focus. | |
| virtual wxString | GetCommandGroupName () |
| return the command group name for commands of a derived class | |
| virtual void | DoStopTool (bool abort) |
| to do tool specific stuff to stop a tool. Called from StopTool(). | |
| virtual bool | EnterBusyMode () |
| starts a new action (e.g drawing something ) in a tool that is already pushed. | |
| virtual void | FinishBusyMode (bool closeCommandGroup=true) |
| Called when the user finishes editing a distinct object */. | |
Protected Attributes | |
| a2dCanvasObjectPtr | m_newObject |
| a2dCanvasObjectPtr | m_parentAddedTo |
| This is the parent, to which the temporary object was added. | |
Detailed Description
Interactive drag a new object into a drawing.This is like a2dDragTool but it goes automatically into drag mode if it receives a mouse event.
- Remarks:
- Left Click to drop.
Key left right up down to move while draging active (Left Down)
- See also:
- a2dDragTool
Definition at line 1072 of file sttool.h.
Constructor & Destructor Documentation
| a2dDragNewTool::a2dDragNewTool | ( | a2dStToolContr * | controller, | |
| a2dCanvasObject * | newObject | |||
| ) |
- Parameters:
-
controller controller to place tool in newObject the canvas object that is drag & droped
Definition at line 3263 of file sttool.cpp.
Member Function Documentation
| bool a2dDragNewTool::ZoomSave | ( | ) | [inline, virtual] |
Is Zooming while the tool is busy Save.
If so, the active tool will redraw itself in the new Mapping state
Reimplemented from a2dDragTool.
| virtual wxString a2dDragNewTool::GetCommandGroupName | ( | ) | [inline, protected, virtual] |
return the command group name for commands of a derived class
this defaults to the class name
Reimplemented from a2dDragTool.
| bool a2dDragNewTool::EnterBusyMode | ( | ) | [protected, virtual] |
starts a new action (e.g drawing something ) in a tool that is already pushed.
Opens a new a2dCommandGroup, which will be closed at the end of an action. This is normally in FinishBusyMode(), but might be delayed when other tools are pushed, like the edit tool to further edit the drawn figure. This should become part of the same command group.
Reimplemented from a2dDragTool.
Definition at line 3388 of file sttool.cpp.
| void a2dDragNewTool::FinishBusyMode | ( | bool | closeCommandGroup = true |
) | [protected, virtual] |
Called when the user finishes editing a distinct object */.
- See also:
- EnterBusyMode,
GetActive You should call the base class (this) version at the END of your function
Reimplemented from a2dDragTool.
Definition at line 3402 of file sttool.cpp.
Member Data Documentation
a2dCanvasObjectPtr a2dDragNewTool::m_parentAddedTo [protected] |
The documentation for this class was generated from the following files:
