a2dDrawPolylineLToolFast Class Reference
[Objects used for interactive manipulation.]
Interactive drawing of a polyline.
More...
#include <sttool2.h>
Public Member Functions | |
| a2dDrawPolylineLToolFast (a2dStToolContr *controller, a2dPolylineL *templateObject=NULL) | |
| constructor | |
| void | SetLineBegin (a2dCanvasObject *begin) |
| defines line begin object for line and polyline drawing tools | |
| void | SetLineEnd (a2dCanvasObject *end) |
| defines line end object for line and polyline drawing tools | |
| a2dCanvasObject * | GetLineBegin () |
| get current line begin object for line and polyline drawing tools. | |
| a2dCanvasObject * | GetLineEnd () |
| get current line end object for line and polyline drawing tools | |
| void | SetEndScaleX (double xs) |
| scaling in X for begin and end objects of linres and polylines | |
| void | SetEndScaleY (double ys) |
| scaling in Y for begin and end objects of linres and polylines | |
| double | GetEndScaleX () |
| get scaling in X for begin and end objects of lines and polylines | |
| double | GetEndScaleY () |
| get scaling in Y for begin and end objects of lines and polylines | |
| void | SetPathType (a2dPATH_END_TYPE pathtype) |
| Set when m_contourwidth != 0 what is the end of the line should be. | |
| a2dPATH_END_TYPE | GetPathType () |
| get when m_contourwidth != 0 what is the end of the line looks like. | |
Static Public Attributes | |
| static const a2dCommandId | COMID_PushTool_DrawPolylineLFast |
| push this tool on the tools stack | |
| static const a2dCommandId | COMID_PushTool_DrawPolylineLFast_Splined |
| push this tool on the tools stack | |
Protected Member Functions | |
| bool | CreateToolObjects () |
| Create the editcopy and other tool objects (e.g. decorations). | |
| void | OnMouseEvent (wxMouseEvent &event) |
| called on mouse events | |
| void | OnDoEvent (a2dCommandProcessorEvent &event) |
| handler for Do event | |
Protected Attributes | |
| a2dCanvasObjectPtr | m_begin |
| begin point object for lines and polylines | |
| a2dCanvasObjectPtr | m_end |
| end point object for lines and polylines | |
| double | m_xscale |
| begin point scaling | |
| double | m_yscale |
| end point scaling | |
| a2dPATH_END_TYPE | m_pathtype |
| when m_contourwidth != 0 what is the end of the line looking like. | |
Detailed Description
Interactive drawing of a polyline.
- Remarks:
- Left Click to add points.
Space bar or Double click to end drawing.
Cursor keys to shift object.
Cursor keys + control to shift point.
Right Click to zoom.
- See also:
- a2dStToolContr
Definition at line 501 of file sttool2.h.
Constructor & Destructor Documentation
| a2dDrawPolylineLToolFast::a2dDrawPolylineLToolFast | ( | a2dStToolContr * | controller, | |
| a2dPolylineL * | templateObject = NULL | |||
| ) |
constructor
- Parameters:
-
controller tool controller one which this tool is pushed. templateObject when not NULL, this object is cloned and used for the new drawn object.
Definition at line 2119 of file sttool2.cpp.
Member Function Documentation
| void a2dDrawPolylineLToolFast::SetLineBegin | ( | a2dCanvasObject * | begin | ) |
defines line begin object for line and polyline drawing tools
You might want to reset m_newObjectsGetCommandProcStyle also. Otherwise the command processor will overwrite what you set here
Definition at line 2147 of file sttool2.cpp.
| void a2dDrawPolylineLToolFast::SetLineEnd | ( | a2dCanvasObject * | end | ) |
defines line end object for line and polyline drawing tools
You might want to reset m_newObjectsGetCommandProcStyle also. Otherwise the command processor will overwrite what you set here
Definition at line 2163 of file sttool2.cpp.
| a2dCanvasObject* a2dDrawPolylineLToolFast::GetLineBegin | ( | ) | [inline] |
| a2dCanvasObject* a2dDrawPolylineLToolFast::GetLineEnd | ( | ) | [inline] |
| bool a2dDrawPolylineLToolFast::CreateToolObjects | ( | ) | [protected, virtual] |
Create the editcopy and other tool objects (e.g. decorations).
m_original must be set before this function is called
Reimplemented from a2dDrawPolygonLToolFast.
Definition at line 2316 of file sttool2.cpp.
The documentation for this class was generated from the following files:
