a2dFunctionCurve Class Reference
[a2dCanvasObject related objects, complex canvasobject's, complex canvasobject's for drawing sets of curves]
Object to plot a Curve defined by a Function in form of a string.
More...
#include <curve.h>
Public Member Functions | |
| a2dFunctionCurve (const wxString &curve=_T("Not Specified")) | |
| a2dFunctionCurve (const a2dFunctionCurve &other, CloneOptions options) | |
| virtual a2dObject * | Clone (CloneOptions options) const |
| This is here so that this class cannot be used directly. | |
| void | SetXstep (double xstep) |
| virtual bool | GetXyAtSweep (double sweepValue, a2dPoint2D &point) const |
| return Points in plot at the value of sweep parameter. | |
Protected Member Functions | |
| virtual void | DoSave (wxObject *parent, a2dIOHandlerXmlSerOut &out, a2dXmlSer_flag xmlparts, a2dObjectList *towrite) |
| write object specific CVGL data | |
| void | DoLoad (wxObject *parent, a2dIOHandlerXmlSerIn &parser, a2dXmlSer_flag xmlparts) |
| load object specific CVG data | |
| a2dBoundingBox | DoGetUnTransformedBbox (a2dBboxFlags flags=a2dCANOBJ_BBOX_NON) const |
| bool | DoUpdate (UpdateMode mode, const a2dBoundingBox &childbox, const a2dBoundingBox &clipbox, const a2dBoundingBox &propbox) |
| Update derived Object specific things ( mainly boundingbox). | |
| void | DoRender (a2dIterC &ic, OVERLAP clipparent) |
| render derived object | |
| bool | DoIsHitWorld (a2dIterC &ic, a2dHitEvent &hitEvent) |
| Does hit test on the object (exclusif child objects). | |
Protected Attributes | |
| wxString | m_curve |
| double | m_xstep |
| double | m_xstart |
| double | m_xstop |
Detailed Description
Object to plot a Curve defined by a Function in form of a string.The Function string will be evaluated for each X to get Y on the Curve
Definition at line 237 of file curve.h.
Member Function Documentation
| bool a2dFunctionCurve::GetXyAtSweep | ( | double | sweepValue, | |
| a2dPoint2D & | point | |||
| ) | const [virtual] |
return Points in plot at the value of sweep parameter.
In general the sweep parameter is the x value in the plot data, and returned will be the x,y and that x. But in case of complex data x,y = Function( freq ), this here will return the x,y and freq.
- Returns:
- false when the sweep is outside of range.
Implements a2dCurve.
| void a2dFunctionCurve::DoLoad | ( | wxObject * | parent, | |
| a2dIOHandlerXmlSerIn & | parser, | |||
| a2dXmlSer_flag | xmlparts | |||
| ) | [protected, virtual] |
| bool a2dFunctionCurve::DoUpdate | ( | UpdateMode | mode, | |
| const a2dBoundingBox & | childbox, | |||
| const a2dBoundingBox & | clipbox, | |||
| const a2dBoundingBox & | propbox | |||
| ) | [protected, virtual] |
Update derived Object specific things ( mainly boundingbox).
Calculates the boundingbox of the object (exclusif base class child objects but with other nested objects).
- Parameters:
-
mode way to update the objects childbox size of children boundingbox clipbox clip to this propbox size of properties boundingbox
- Remarks:
- in a derived class this function can also be used to update object specific cache data.
force may or may not have direct influence on the object itself, if this function is called directly for some reason (e.g from derived objects), you must invalidate the boudingbox yourself. GetDrawerBox()->SetValid( false );
Reimplemented from a2dCurveObject.
render derived object
if the object has sub objects (apart from the childobject which are handled here), those subobject most rendered by iterating on layer when needed/wanted, simular to child objects. We do not iterate here, since that is only needed if indeed there or subobjects. This will be know in a "wxDerivedCanvasObject DoRender".
SO parent objects that call this function, must:
- 1- clip object against area to redraw.
- 2- iterate on layers when needed.
Reimplemented from a2dCanvasObject.
| bool a2dFunctionCurve::DoIsHitWorld | ( | a2dIterC & | ic, | |
| a2dHitEvent & | hitEvent | |||
| ) | [protected, virtual] |
Does hit test on the object (exclusif child objects).
DoIsHitWorld() should return the way the object is hit by filling a2dHitEvent::m_how with the correct info.
- Parameters:
-
ic iterative context ( e.g. current transform WITH the local transform applied ) hitEvent stores hit information
- Returns:
- true if hit
Reimplemented from a2dCanvasObject.
The documentation for this class was generated from the following files:
